| DC01+Z Commercial Grade Anti Corrosion |
GB/T 2518 DC01+Z
ASTM A1008 CS Type A
JIS G3302 SGCC
EN 10152 DX51D+Z |
Tensile 270–410 MPa
Yield ≥140 MPa
Elongation ≥38%
Double-sided Zinc Coating Weight: 60–275 g/㎡ (8–38 μm)
Neutral Salt Spray Test: ≥72h No White Rust, ≥500h No Red Rust
Coating Adhesion: Conforms to GB/T 2694 & ASTM A123
Regular/Zero Spangle Available |
Thickness 0.15–3.0 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1800 mm
Coil Weight 3–8 tons
Custom Sizes & Coating Weight Available |
C≤0.12, Si≤0.30
Mn≤0.60, P≤0.045, S≤0.045, Al≥0.020 |
| DC03+Z Stamping Grade Anti Corrosion |
GB/T 2518 DC03+Z
ASTM A1008 CS Type B
JIS G3302 SGCD1
EN 10152 DX52D+Z |
Tensile 270–370 MPa
Yield ≥120 MPa
Elongation ≥42%
Double-sided Zinc Coating Weight: 60–275 g/㎡ (8–38 μm)
Neutral Salt Spray Test: ≥72h No White Rust, ≥500h No Red Rust
Coating Adhesion: Conforms to GB/T 2694 & ASTM A123
Regular/Zero Spangle Available |
Thickness 0.2–2.5 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1800 mm
Coil Weight 3–8 tons
Custom Sizes & Coating Weight Available |
C≤0.10, Si≤0.30
Mn≤0.45, P≤0.035, S≤0.035, Al≥0.020 |
| DC04+Z Deep Drawing Grade Anti Corrosion |
GB/T 2518 DC04+Z
ASTM A1008 DDS Type A
JIS G3302 SGCD2
EN 10152 DX53D+Z |
Tensile 270–350 MPa
Yield ≥100 MPa
Elongation ≥46%
Double-sided Zinc Coating Weight: 60–275 g/㎡ (8–38 μm)
Neutral Salt Spray Test: ≥72h No White Rust, ≥500h No Red Rust
Coating Adhesion: Conforms to GB/T 2694 & ASTM A123
Regular/Zero Spangle Available |
Thickness 0.3–2.0 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1600 mm
Coil Weight 3–6 tons
Custom Sizes & Coating Weight Available |
C≤0.08, Si≤0.30
Mn≤0.40, P≤0.030, S≤0.030, Al≥0.020 |
| DC05+Z Extra Deep Drawing Grade Anti Corrosion |
GB/T 2518 DC05+Z
ASTM A1008 DDS Type B
JIS G3302 SGCD3
EN 10152 DX54D+Z |
Tensile 250–330 MPa
Yield ≥90 MPa
Elongation ≥48%
Double-sided Zinc Coating Weight: 60–275 g/㎡ (8–38 μm)
Neutral Salt Spray Test: ≥72h No White Rust, ≥500h No Red Rust
Coating Adhesion: Conforms to GB/T 2694 & ASTM A123
Regular/Zero Spangle Available |
Thickness 0.4–1.8 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1600 mm
Coil Weight 3–6 tons
Custom Sizes & Coating Weight Available |
C≤0.06, Si≤0.30
Mn≤0.35, P≤0.025, S≤0.025, Al≥0.020 |
| DC06+Z Super Extra Deep Drawing Grade Anti Corrosion |
GB/T 2518 DC06+Z
ASTM A1008 EDDS
JIS G3302 SGCD4
EN 10152 DX56D+Z |
Tensile 240–320 MPa
Yield ≥80 MPa
Elongation ≥50%
Double-sided Zinc Coating Weight: 60–275 g/㎡ (8–38 μm)
Neutral Salt Spray Test: ≥72h No White Rust, ≥500h No Red Rust
Coating Adhesion: Conforms to GB/T 2694 & ASTM A123
Regular/Zero Spangle Available |
Thickness 0.5–1.5 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1600 mm
Coil Weight 3–5 tons
Custom Sizes & Coating Weight Available |
C≤0.04, Si≤0.30
Mn≤0.30, P≤0.020, S≤0.020, Al≥0.020 |
| Q195+Z Commercial Structural Grade Anti Corrosion |
GB/T 2518 Q195+Z
ASTM A1008 CS Type A
EN 10152 DX51D+Z
JIS G3302 SGCC |
Tensile 315–430 MPa
Yield ≥195 MPa
Elongation ≥30%
Double-sided Zinc Coating Weight: 60–275 g/㎡ (8–38 μm)
Neutral Salt Spray Test: ≥72h No White Rust, ≥500h No Red Rust
Coating Adhesion: Conforms to GB/T 2694
Regular/Zero Spangle Available |
Thickness 0.25–3.0 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1800 mm
Coil Weight 3–8 tons
Custom Sizes & Coating Weight Available |
C≤0.12, Si≤0.30
Mn≤0.50, P≤0.045, S≤0.045 |
| Q235B+Z General Structural Grade Anti Corrosion |
GB/T 2518 Q235B+Z
ASTM A1008 CS Type B
EN 10152 DX52D+Z
JIS G3302 SGCD1 |
Tensile 370–500 MPa
Yield ≥235 MPa
Elongation ≥26%
Double-sided Zinc Coating Weight: 60–275 g/㎡ (8–38 μm)
Neutral Salt Spray Test: ≥72h No White Rust, ≥500h No Red Rust
Coating Adhesion: Conforms to GB/T 2694
Regular/Zero Spangle Available |
Thickness 0.3–3.0 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1800 mm
Coil Weight 3–8 tons
Custom Sizes & Coating Weight Available |
C≤0.22, Si≤0.35
Mn≤1.40, P≤0.045, S≤0.045 |
| Q355B+Z High Strength Low Alloy Anti Corrosion |
GB/T 2518 Q355B+Z
ASTM A1008 HSLA Grade 50
EN 10152 S355GD+Z
JIS G3302 SGHC440 |
Tensile ≥470 MPa
Yield ≥355 MPa
Elongation ≥21%
Double-sided Zinc Coating Weight: 60–275 g/㎡ (8–38 μm)
Neutral Salt Spray Test: ≥72h No White Rust, ≥500h No Red Rust
Coating Adhesion: Conforms to GB/T 2694
Regular/Zero Spangle Available |
Thickness 0.4–3.0 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1800 mm
Coil Weight 3–8 tons
Custom Sizes & Coating Weight Available |
C≤0.24, Si≤0.55
Mn≤1.60, P≤0.035, S≤0.035 |
| Q420B+Z Ultra High Strength Low Alloy Anti Corrosion |
GB/T 2518 Q420B+Z
ASTM A1008 HSLA Grade 60
EN 10152 S420GD+Z
JIS G3302 SGHC490 |
Tensile ≥520 MPa
Yield ≥420 MPa
Elongation ≥19%
Double-sided Zinc Coating Weight: 60–275 g/㎡ (8–38 μm)
Neutral Salt Spray Test: ≥72h No White Rust, ≥500h No Red Rust
Coating Adhesion: Conforms to GB/T 2694
Regular/Zero Spangle Available |
Thickness 0.5–2.5 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1600 mm
Coil Weight 3–6 tons
Custom Sizes & Coating Weight Available |
C≤0.20, Si≤0.55
Mn≤1.70, P≤0.030, S≤0.030 |
| High Zinc Coating Grade Anti Corrosion |
GB/T 2518 DC01/DC03+Z
ASTM A1008 CS Type A/B
EN 10152 DX51D/DX52D+Z
JIS G3302 SGCC/SGCD1 |
Tensile 270–410 MPa
Yield ≥140 MPa
Elongation ≥38%
Double-sided Zinc Coating Weight: 275–600 g/㎡ (38–85 μm)
Neutral Salt Spray Test: ≥1000h No White Rust, ≥2000h No Red Rust
Coating Adhesion: Conforms to GB/T 2694 & ASTM A123
Regular/Zero Spangle Available |
Thickness 0.15–3.0 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1800 mm
Coil Weight 3–8 tons
Custom Sizes & Coating Weight Available |
C≤0.12, Si≤0.30
Mn≤0.60, P≤0.045, S≤0.045, Al≥0.020 |
| DC01+ZM Zn-Al-Mg Alloy Ultra High Anti Corrosion |
GB/T 31901 DC01+ZM
ASTM A792 AZM150
EN 10346 DX51D+ZM
JIS G3321 SGLC400 |
Tensile 270–410 MPa
Yield ≥140 MPa
Elongation ≥38%
Double-sided Zn-Al-Mg Alloy Coating Weight: 150–400 g/㎡
Neutral Salt Spray Test: ≥2000h No White Rust, ≥4000h No Red Rust
Superior Corrosion Resistance in Coastal, Industrial & High Humidity Environments
Zero Spangle Smooth Surface |
Thickness 0.2–2.5 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1600 mm
Coil Weight 3–6 tons
Custom Sizes & Coating Weight Available |
C≤0.12, Si≤0.30
Mn≤0.60, P≤0.045, S≤0.045, Al≥0.020
Coating: Zn 80-95%, Al 3-10%, Mg 1-3% |
| DC03+ZM Zn-Al-Mg Alloy Stamping Grade Ultra High Anti Corrosion |
GB/T 31901 DC03+ZM
ASTM A792 AZM150
EN 10346 DX52D+ZM
JIS G3321 SGLC400 |
Tensile 270–370 MPa
Yield ≥120 MPa
Elongation ≥42%
Double-sided Zn-Al-Mg Alloy Coating Weight: 150–400 g/㎡
Neutral Salt Spray Test: ≥2000h No White Rust, ≥4000h No Red Rust
Excellent Stamping Performance + Ultra High Corrosion Resistance for Auto Parts & Home Appliances
Zero Spangle Smooth Surface |
Thickness 0.3–2.0 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1600 mm
Coil Weight 3–6 tons
Custom Sizes & Coating Weight Available |
C≤0.10, Si≤0.30
Mn≤0.45, P≤0.035, S≤0.035, Al≥0.020
Coating: Zn 80-95%, Al 3-10%, Mg 1-3% |
| DC04+ZnNi Zinc-Nickel Alloy Automotive Grade High Anti Corrosion |
GB/T 20492 DC04+ZnNi
ASTM A879 ZnNi10
EN 10346 DX53D+ZnNi
JIS G3317 SGZN10 |
Tensile 270–350 MPa
Yield ≥100 MPa
Elongation ≥46%
Double-sided Zn-Ni Alloy Coating Weight: 100–300 g/㎡
Neutral Salt Spray Test: ≥1500h No White Rust, ≥3000h No Red Rust
Superior Corrosion Resistance for Automotive Chassis & Body Parts
Excellent Weldability & Paint Adhesion |
Thickness 0.3–2.0 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1600 mm
Coil Weight 3–6 tons
Custom Sizes & Coating Weight Available |
C≤0.08, Si≤0.30
Mn≤0.40, P≤0.030, S≤0.030, Al≥0.020
Coating: Zn 85-95%, Ni 5-15% |
| DC03+ZnFe Zinc-Iron Alloy Home Appliance Grade High Anti Corrosion |
GB/T 14978 DC03+ZnFe
ASTM A653 ZnFe12
EN 10346 DX52D+ZnFe
JIS G3316 SGHF12 |
Tensile 270–370 MPa
Yield ≥120 MPa
Elongation ≥42%
Double-sided Zn-Fe Alloy Coating Weight: 120–300 g/㎡
Neutral Salt Spray Test: ≥1200h No White Rust, ≥2500h No Red Rust
Excellent Corrosion Resistance & Paint Adhesion for Home Appliance Shells & Liners
Good Stamping Performance |
Thickness 0.3–2.5 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1800 mm
Coil Weight 3–8 tons
Custom Sizes & Coating Weight Available |
C≤0.10, Si≤0.30
Mn≤0.45, P≤0.035, S≤0.035, Al≥0.020
Coating: Zn 80-90%, Fe 10-20% |
| ASTM A1008 CS Type A Commercial Grade Anti Corrosion |
ASTM A1008 CS Type A
GB/T 2518 DC01+Z
EN 10152 DX51D+Z
JIS G3302 SGCC |
Tensile 270–410 MPa
Yield ≥140 MPa
Elongation ≥38%
Double-sided Zinc Coating Weight: 60–275 g/㎡ (8–38 μm)
Neutral Salt Spray Test: ≥72h No White Rust, ≥500h No Red Rust
Conforms to ASTM A1008 Standard
Regular/Zero Spangle Available |
Thickness 0.15–3.0 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1800 mm
Coil Weight 3–8 tons
Custom Sizes & Coating Weight Available |
C≤0.15, Si≤0.30
Mn≤0.60, P≤0.040, S≤0.050, Al≥0.020 |
| ASTM A1008 DDS Deep Drawing Grade Anti Corrosion |
ASTM A1008 DDS
GB/T 2518 DC04+Z
EN 10152 DX53D+Z
JIS G3302 SGCD2 |
Tensile 270–350 MPa
Yield ≥100 MPa
Elongation ≥46%
Double-sided Zinc Coating Weight: 60–275 g/㎡ (8–38 μm)
Neutral Salt Spray Test: ≥72h No White Rust, ≥500h No Red Rust
Conforms to ASTM A1008 Standard
Regular/Zero Spangle Available |
Thickness 0.3–2.0 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1600 mm
Coil Weight 3–6 tons
Custom Sizes & Coating Weight Available |
C≤0.10, Si≤0.30
Mn≤0.45, P≤0.030, S≤0.035, Al≥0.020 |
| ASTM A1008 HSLA Grade 50 High Strength Anti Corrosion |
ASTM A1008 HSLA Grade 50
GB/T 2518 Q355B+Z
EN 10152 S355GD+Z
JIS G3302 SGHC440 |
Tensile 485–620 MPa
Yield ≥345 MPa
Elongation ≥22%
Double-sided Zinc Coating Weight: 60–275 g/㎡ (8–38 μm)
Neutral Salt Spray Test: ≥72h No White Rust, ≥500h No Red Rust
Conforms to ASTM A1008 Standard
Regular/Zero Spangle Available |
Thickness 0.4–3.0 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1800 mm
Coil Weight 3–8 tons
Custom Sizes & Coating Weight Available |
C≤0.23, Si≤0.40
Mn≤1.35, P≤0.035, S≤0.040 |
| EN 10152 DX51D+Z Commercial Grade Anti Corrosion |
EN 10152 DX51D+Z
GB/T 2518 DC01+Z
ASTM A1008 CS Type A
JIS G3302 SGCC |
Tensile 270–410 MPa
Yield ≥140 MPa
Elongation ≥38%
Double-sided Zinc Coating Weight: 60–275 g/㎡ (8–38 μm)
Neutral Salt Spray Test: ≥72h No White Rust, ≥500h No Red Rust
Conforms to EN 10152 Standard
Regular/Zero Spangle Available |
Thickness 0.15–3.0 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1800 mm
Coil Weight 3–8 tons
Custom Sizes & Coating Weight Available |
C≤0.12, Si≤0.30
Mn≤0.60, P≤0.045, S≤0.045, Al≥0.020 |
| EN 10152 DX53D+Z Deep Drawing Grade Anti Corrosion |
EN 10152 DX53D+Z
GB/T 2518 DC04+Z
ASTM A1008 DDS Type A
JIS G3302 SGCD2 |
Tensile 270–350 MPa
Yield ≥100 MPa
Elongation ≥46%
Double-sided Zinc Coating Weight: 60–275 g/㎡ (8–38 μm)
Neutral Salt Spray Test: ≥72h No White Rust, ≥500h No Red Rust
Conforms to EN 10152 Standard
Regular/Zero Spangle Available |
Thickness 0.3–2.0 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1600 mm
Coil Weight 3–6 tons
Custom Sizes & Coating Weight Available |
C≤0.08, Si≤0.30
Mn≤0.40, P≤0.030, S≤0.030, Al≥0.020 |
| EN 10152 S355GD+Z High Strength Anti Corrosion |
EN 10152 S355GD+Z
GB/T 2518 Q355B+Z
ASTM A1008 HSLA Grade 50
JIS G3302 SGHC440 |
Tensile ≥470 MPa
Yield ≥355 MPa
Elongation ≥21%
Double-sided Zinc Coating Weight: 60–275 g/㎡ (8–38 μm)
Neutral Salt Spray Test: ≥72h No White Rust, ≥500h No Red Rust
Conforms to EN 10152 Standard
Regular/Zero Spangle Available |
Thickness 0.4–3.0 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1800 mm
Coil Weight 3–8 tons
Custom Sizes & Coating Weight Available |
C≤0.24, Si≤0.55
Mn≤1.60, P≤0.035, S≤0.035 |
| JIS G3302 SGCC Commercial Grade Anti Corrosion |
JIS G3302 SGCC
GB/T 2518 DC01+Z
ASTM A1008 CS Type A
EN 10152 DX51D+Z |
Tensile 270–410 MPa
Yield ≥140 MPa
Elongation ≥38%
Double-sided Zinc Coating Weight: 60–275 g/㎡ (8–38 μm)
Neutral Salt Spray Test: ≥72h No White Rust, ≥500h No Red Rust
Conforms to JIS G3302 Standard
Regular/Zero Spangle Available |
Thickness 0.15–3.0 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1800 mm
Coil Weight 3–8 tons
Custom Sizes & Coating Weight Available |
C≤0.12, Si≤0.30
Mn≤0.60, P≤0.045, S≤0.045, Al≥0.020 |
| JIS G3302 SGCD2 Deep Drawing Grade Anti Corrosion |
JIS G3302 SGCD2
GB/T 2518 DC04+Z
ASTM A1008 DDS Type A
EN 10152 DX53D+Z |
Tensile 270–350 MPa
Yield ≥100 MPa
Elongation ≥46%
Double-sided Zinc Coating Weight: 60–275 g/㎡ (8–38 μm)
Neutral Salt Spray Test: ≥72h No White Rust, ≥500h No Red Rust
Conforms to JIS G3302 Standard
Regular/Zero Spangle Available |
Thickness 0.3–2.0 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1600 mm
Coil Weight 3–6 tons
Custom Sizes & Coating Weight Available |
C≤0.08, Si≤0.30
Mn≤0.40, P≤0.030, S≤0.030, Al≥0.020 |
| JIS G3302 SGHC440 High Strength Anti Corrosion |
JIS G3302 SGHC440
GB/T 2518 Q355B+Z
ASTM A1008 HSLA Grade 50
EN 10152 S355GD+Z |
Tensile ≥440 MPa
Yield ≥340 MPa
Elongation ≥22%
Double-sided Zinc Coating Weight: 60–275 g/㎡ (8–38 μm)
Neutral Salt Spray Test: ≥72h No White Rust, ≥500h No Red Rust
Conforms to JIS G3302 Standard
Regular/Zero Spangle Available |
Thickness 0.4–3.0 mm
Width 1000–1500 mm
Coil ID 508/610 mm
Coil OD 1000–1800 mm
Coil Weight 3–8 tons
Custom Sizes & Coating Weight Available |
C≤0.23, Si≤0.40
Mn≤1.35, P≤0.035, S≤0.040 |
